Solutions by Theme

Product Information » Solutions by Theme » Proposal for Installation of Thermo-chiller » Thermo-chiller Variations

Thermo-chiller Variations

|Thermo-chiller Variations

Series	Features	Temperature range setting	Cooling capacity	Cooling method	Temperature stability	Power supply	Circulating fluid
	With this chiller, cooling water can be supplied to anywhere it is necessary because of its easy installation and easy operation. For a wide range of applications, such as laser machine tools, analytical equipment, LCD manufacturing equipment, mold temperature control, etc. Compact:W377 x H615 x D500 mm, 40 kg (HRS012/018/024) Timer function, Low liquid level protection, Power failure auto-restart, Anti-freezing function, etc. Self diagnosis function No heater required, as circulating fluid is heated using heat exhausted by refrigerating circuit. Low-noise design: 70 dB (A) (HRS100/150) Outdoor installation: IPX4 (HRS100/150)	5 to 40℃	1.3kW 1.9kW 2.4kW 3.2kW 5.1kW 5.9kW (60 Hz)	Aircooled Watercooled	±0.1℃	Single-phase 100 VAC (50/60 Hz) Single-phase 115 VAC (60 Hz) Single-phase 200 to 230 VAC (50/60 Hz)	Tap water Deionized water Ethylene glycol aqueous solution (15%)
		5 to 35℃	9kW	Aircooled Watercooled	±0.5℃	Single-phase 100 VAC (50/60 Hz) Single-phase 115 VAC (60 Hz) Single-phase 200 to 230 VAC (50/60 Hz)	Tap water Deionized water Ethylene glycol aqueous solution (15%)
		5 to 35℃	9.5kW 14.5kW (60Hz)	Aircooled Watercooled	±0.1℃	Single-phase 100 VAC (50/60 Hz) Single-phase 115 VAC (60 Hz) Single-phase 200 to 230 VAC (50/60 Hz)	Tap water Deionized water Ethylene glycol aqueous solution (15%)
	Reduces power consumption by 53% Complete with energy-saving triple inverter! Compact/Space-saving: W377 x H1080 x D970 mm Max. ambient temperature: 45°C	5 to 40℃	9.5kW	Aircooled Watercooled	±0.1℃	3-phase 200 VAC (50 Hz) 3-phase 200 to 230 VAC (60 Hz) 3-phase 380 to 415 VAC (50/60 Hz)	Tap water Deionized water Ethylene glycol aqueous solution (15%)
	Complete with energy-saving triple inverter! Outdoor installation: IPX4 Max. ambient temperature: 45°C Space-saving, Lightweight: 280 kg (HRSH250/300)	5 to 35℃	10kW 15kW 20kW 25kW 28kW	Aircooled Watercooled	±0.1℃	3-phase 200 VAC (50 Hz) 3-phase 200 to 230 VAC (60 Hz) 3-phase 380 to 415 VAC (50/60 Hz)	Tap water Deionized water Ethylene glycol aqueous solution (15%)
	Simple function and performance. Thermo-chiller basic type. Complete with energy-saving triple control! Reduces power consumption by 33% Compact/Lightweight: 32 kg (100 VAC) Maintenance free: Magnet pump Low-noise design: 55 dB (A)	5 to 40℃	1.2kW 1.6kW 2.2kW (60Hz)	Aircooled	±2.0℃	Single-phase 100 VAC (50/60 Hz) Single-phase 200 VAC (50/60 Hz) Single-phase 230 VAC (50/60 Hz)	Tap water Ethylene glycol aqueous solution (15%)
