For High Precision Positioning Pin Shift Cylinder CKQG-X2370
Arc Welding Process Equipment ? Specialty Cylinders
-
?High Precision: Rod end deflection ±0.1 mm or less
?Position Reproducibility
?Pin for positioning the workpiece provided by the customer can be directly mounted.
?Built-in coil scraper
?Reduces labor time by integrating the cylinder and guide.
?Magnetic field resistant auto switches are mountable.
Safety Instructions Actuators/Precautions Auto Switches/Precautions
Specialized Products for General Use Introduction of Arc Welding Process Equipment
Green Procurement (RoHS)
Specialized Products for General Use Introduction of Arc Welding Process Equipment
Green Procurement (RoHS)
| Type | Series | Bore size（mm） | Stroke（mm） |
|---|---|---|---|
| Built-in standard magnet type | CKQG-X2370 | 32, 40, 50 | 25, 30, 40, 50 |
Offset Pin Shift Cylinder CDQ2B-X2839
Air Cylinders ? Pin Shift CylinderArc Welding Process Equipment ? Specialty Cylinders
-
?With high rigidity offset load capacity
?High rigidity, High precision
With plate extended: Deflection of ±0.1 mm or less
?3 different port location directions can be selected.
?Can be mounted from 2 directions
?Coil scrapers equipped as standard
?Auto switches are mountable.
| Type | Series | Bore size (mm) | Stroke (mm) |
|---|---|---|---|
| Offset pin shift cylinder | CDQ2B-X2839 | 32, 40, 50 | 25, 50, 75 |
Slim-line Power Clamp Cylinder CKZ2N-X2346
Air Cylinders ? Clamp CylindersArc Welding Process Equipment ? Specialty Cylinders
-
?The distance accuracy from the reference hole to the lower surface of the clamp arm is ±0.1 mm.
?Easy setup with a scale
The guide of the appropriate position can be checked visually when adjusting the shim.
?Reduced width
Easy torch entry for spot welding, arc welding, etc.
Safety Instructions Actuators/Precautions Auto Switches/Precautions
Introduction of Arc Welding Process Equipment Green Procurement (RoHS)
Introduction of Arc Welding Process Equipment Green Procurement (RoHS)
| Series | Arm opening angle | Bore size (mm) |
|---|---|---|
| CKZ2N-X2346 | 30o, 45o, 60o, 75o, 90o 105o, 120o, 135o | 50, 63, 80 |
Frame Clamp Cylinder WRF100
Air Cylinders ? Clamp CylindersArc Welding Process Equipment ? Specialty Cylinders
Safety Instructions Actuators/Precautions Introduction of Arc Welding Process Equipment
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Bore size (mm) | Stroke (mm) |
|---|---|---|
| WRF100 | 100 | 48 |
Compact Clamp Unit CDQ2
Arc Welding Process Equipment ? Specialty Cylinders
-
?Space saving
Used to clamp the workpiece, and open or close the spatter cover of the workpiece.
?Labor reduction
Reduces design and assembly labor by integrating the cylinder and clamping mechanism.
?Clamp unit used in common
Both ?20 and ?32 clamp cylinders use the same clamp unit and only the clamp unit can be replaced.
This contributes to reduction of spare parts.
?Possible to clamp in both directions
Capable of clamping in both directions with an arm opening/closing angle of 90° or more
Safety Instructions Actuators/PrecautionsSpecialized Products for General Use
Introduction of Arc Welding Process Equipment Green Procurement (RoHS)
Introduction of Arc Welding Process Equipment Green Procurement (RoHS)
| Series | Bore size（mm） | Arm opening angle |
|---|---|---|
| CDQ2B20-DCT1710T | 20 | 96° |
| CDQ2B32-DCR0859R | 32 | 96° |
Center Lock Unit MA331-X441
Air Cylinders ? Pin Shift CylinderArc Welding Process Equipment ? Specialty Cylinders
-
?The workpiece contact portion of the locating pin can switch from center lock (for locating) to free (for releasing workpieces).
?Even if the workpiece is distorted after welding, if the locating pin is set to free, the workpiece can be removed easily from the locating pin.
?Locating pin swing angle and rotation angle: 3° ±1°
| Series | Action | Handling air pressure |
|---|---|---|
| MA331-X441 | Double acting | 0.2 to 0.7 MPa |
Magnet Gripper MHM-X6400
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Special PadsArc Welding Process Equipment ? Specialty Cylinders
Rotary Actuators/Air Grippers ? Magnet Grippers
-
?Steel plates can be transferred without a vacuum.
Can support workpieces with holes and uneven surfaces when a vacuum pad cannot be used
?Holds workpieces even when the air is shut off
?High holding force: 80 N (Workpiece plate thickness: 0.6 mm), 120 N
(Workpiece plate thickness: 1.4 mm)
?Residual holding force: 0.3 N or less (Reduces workpiece release time)
| Series | Holding force (Workpiece plate thickness: 0.6 mm) |
|---|---|
| MHM-32D1-X6400 | 80 N |
| MHM-32D2-X6400 | 50 N |
| MHM-32D3-X6400 | 30 N |
